System type: 2 units, 2 frequency division and phase inversion
Rated power: 350W
Maximum power: 700W
Nominal impedance: 8 ohms
Recommended amplifier rated output power: 500w-700w @ 8 ohms
Nominal sensitivity (1W @ 1m): 97dB
Maximum sound pressure level: 122dB @ 350W (125dB @ 700W)
Frequency bandwidth (- 6dB): 46Hz-18KHz
Nominal directivity (- 6dB): 90 ° h × 70 ° V
Transducer configuration: ferrite low frequency driver 15 ″ (380mm unit 65mm voice coil) × 1
Ferrite high frequency driver 1.7 ″ (44 mM voice coil) × 1
Frequency division mode: passive
Connector: peakon NL4 × 2 (Pin1 + / 2 + pos. Pin1 - / 2-neg)
Box material: 15mm (0.6 ″) MDF
Color: black paint by default, other colors can be customized as required
Box size: w440 * d452 * h700mm
Package size: W510*D525*H775mm
Weight (each): 27.2kg/30.45kg
Reference application: suitable for fixed installation of multi-functional hall, auditorium, lecture hall, meeting room, KTV, wine bar, etc
