System type: 2 units, 2 frequency division and phase inversion
Rated power: 250W
Maximum power: 500W
Nominal impedance: 8 ohms
Nominal sensitivity (1W @ 1m): 96dB
Maximum sound pressure level: 120dB @ 250W (123dB @ 500W)
Frequency bandwidth (- 6dB): 60Hz-18KHz
Nominal directivity (- 6dB): 90 ° h × 60 ° V
Transducer configuration: ferrite low frequency driver 10 ″ (250mm unit 65mm voice coil) × 1
Ferrite high frequency driver 1.7 ″ (44 mM voice coil) × 1
Connector: peakon NL4 × 2 (Pin1 + / 2 + pos. Pin1 - / 2-neg)
Box material: 15mm (0.60 ″) plywood
Box size: w292 * d327 * h523mm
Weight (each): 17.15kg
